KA-C10-PW

Quad Core Cortex A55, RK3568

PRODUCTS

Innovative Technology | Reliable Quality | End-to-End Service

اسپیکر کی دی تی مدل KA-C10-PW

قابلیت های هوشمند:

ارتباط با انواع سرور PBX / KDT VOIP Server / ASTERISK / FREEPBX
ارتباط از طریق LAN با قابلیت PoE
قابلیت تعریف اکانت SIP
دارای 150 مگابایت کارت حافظه داخلی
دارای وب جهت تنظیمات و مانیتورینگ بلندگو و کنترل پخش
قابلیت آپلود مستقیم فایل صوتی و پخش از طریق وب بلندگو
قابلیت پخش صوت به صورت زمان بندی شده
استفاده از رمزنگاری JWT با الگوریتم HS256
مانیتورینگ وضعیت سخت افزاری و دمای داخلی بلندگو

KA-C10-PW

Central Network Management
CPU: Quad Core Cortex A55, RK3568
RAM: 4GB
Internal Memory: 16 GB
Touch Screen: 10-Point Capacitive Touch
Panel: 10.1 Inch LCD IPS Panel
Resolution: 1280*800
Wifi: 802.11b/g/n
Ethernet: RJ45, 100M/1000M
Video Format: MPEG, H.264

شرایط گارانتی :

> دو سال گارانتی نقره ای بدون قید و شرط کی دی تی

> سه سال ضمانت پایداری کیفیت صدا

دانلود دیتاشیت
دانلود نرم افزار
System
CPU Quad Core Cortex A55, RK3568
RAM 4 GB
Internal Memory 16 GB
Operation System Linux / Debian 11
Touch Screen 10-Point Capacitive Touch
Display 10.1 Inch LCD IPS Panel
Resolution 1280*800
Contrast Ratio 800
Luminance 250 cd/m2
Aspect Ratio 16:10
Network
Wifi 802.11b/g/n
Ethernet RJ45, 100M/1000M
Bluetooth Bluetooth 5.2
Interface
Card Slot up to 32GB
USB Yes
HDMI N/A
Power Jack DC Power Input
Earphone 3.5mm Earphone With Microphone
Serial Port Yes
RJ45 RJ45, 100M/1000M (PoE Function, Optional)
Microphone Yes
Speaker 2*1W
Media Play
Video Format MPEG, H.264
Audio Format MP3/WMA/AAC etc.
Photo Jpeg
General
Power Supply IEEE802.3at / DC 12 V 1A
Language Persian
Weight 950 g
Mounting Wall Mount
Operation Humidity Humidity 70% or less (non-condensing)
Operation Temp -30°C ~ +60°C
Dimension And Impedance 247*173*37 mm
Material, Colour ABS White / Black
Software Feature
  • SIP Calling Capability
  • Playing Music on SIP Calls
  • Simultaneous Playback of Music and Internal Microphone on SIP Calls
  • Ability to Add SIP Phone Groups on KDT SIP Server
  • Making Calls over RTP without the need for a SIP server with dedicated numbers
  • High-quality Music Playback through Multicast without the need for a server
  • Monitoring KDT Speakers in the network and giving commands to them
  • Individual Volume Control for each Speaker
  • Displaying Temperature and CPU load for each Speaker
  • Identifying Connected and Disconnected Speakers in the network
  • Resetting and muting each connected Speaker when needed
  • Dedicated space for storing music files on the console via USB flash drive
Guarantee
Product Guarantee 2 Years Silver Guarantee
MTBF 100k hrs min. MIL-HDBK-217F (25°)
Certificates EN, CN, FCC
